Olympus SZ-30MR camera is having a 3.0″ high-resolution LCD with 460k dots, a 16MP backside-illuminated CMOS sensor with 24x (25-600mm) optical zoom, and supports the 3D technology, as it can shoot 3D photos as well.

Olympus SZ-30MR has a Dual Engine TruePic III+ image processor and it is the first one to shoot Full 1080p HD video and 16-megapixel snaps simultaneously or record two movies in different modes or from different angles at the same time. The “MR” suffix stands for “Multi Recording”, and basically means that while you’re shooting 1080p HD video on the SZ-30MR, you can also shoot still images as well. It is having wireless SD card support, you don’t have to connect the camera to a PC to share photos or other content.

Olympus SZ-30MR is sporting HDMI out, high ISO and sensor-based mechanical image stabilization; smart panorama, 3D photo, pet detection, and beauty modes; and SDXC and Eye-Fi card compatibility, i-Auto mode and face and pet detection, Olympus Magic Filters, AF tracking, low-light shooting and high-speed burst at 9 fps. The ISO range is 80 to 3200, and support SDXC memory cards.

You can also choose to shoot one HD movie and one lower resolution one, or combine and match the final appearance by engaging different filters. You can even snap some movie footage from a still picture, as it will automatically record footage before and after you snap your loving photo.

Olympus SZ-30MR Specifications & Price

Full Technical Specifications Of Olympus SZ-30MR

H x W x D69 x 106 x 40 mm
Weight226 grams
Camera TypeCompact Digital
TypeTFT LCD High-Resolution screen
Size3.0 inches (7.6 cm)
Dots460000 dots
Input+/- 2 level brightness adjustment
Digital Zoom4x
Optical Zoom24x Wide-Angle Optical Zoom
Sensor1/2.3″ type back-lit CMOS
16 million effective pixels
16.8 million total pixels
Focal Length Equivalent25 – 600mm
Focal Length4.5 – 108.0mm
Lens construction11 lens in 9 groups
Image StabilisationYes(Lens-shift)
Focus– Standard Mode:Approx.  0.1m – ∞ (wide) / 0.4m – ∞ (tele)
– Macro Mode : 0.1m – ∞ (wide) / 0.4m – ∞ (tele)
– AF Illuminator
Modes– iESP
– Contrast Detection
– AF Tracking
– Macro
– Standard
– Super-Macro
– Spot AF
– Face Detection AF
Closest Focusing Distance3cm
AF modesSingle
Servo AF/AE
Exposure compensation+/- 2EV in 1/3 stop increments
Modes– Program Automatic
– Intelligent Auto
– Scene modes
– Sensor-Shift Stabilization
– 3D modes
– Smart Panorama
– HD Movie mode
– Multi Recording mode
– Magic Filter (Pop Art, Punk, Fisheye, Drawing, Sparkle, Water color, Pin Hole, Soft Focus)
Shutter speed1/1700 sec. –1/4 sec. (up to 4 sec. in Night scene mode)
Image & Movie
Image Sizes– 1M: 1280 x 960
– 2M: 1600 x 1200
– 3M: 2048 x 1536
– 5M: 2560 x 1920
– 8M: 3264 x 2448
– 16M: 4608 x 3456

– VGA: 4608 x 2592
– 16:9: 1920 X 1080; 4608 x 2592

Image FormatStill: JPEG
Movie recording resolution– 320 x 240
– 640 x 480
– 1280 x 720 (720p HD)
– 1920 x 1080 (1080p HD)
Movie Recording System
Recording FormatMPEG- 4
HD Movie Quality– 720p Recording Time: 29 min
– 1080p Recording Time: 29 min
– No limit for VGA Recording time
– Maximum file size: 4GB
ISO Sensitivity– ISO Manual 80, 100, 200, 400, 800,1600, 3200
– Auto
– High Auto
White Balance– Auto
– Overcast
– Tungsten
– Daylight
– Fluorescent 1
Self Timer– 2 or 10 sec
– Perfect Auto Shot Preview
Flash– Red-Aye reduction
– Auto
– Fill-in
– Off
Flash Working Range– Wide: 0.1m (0.33ft) – 9.3m (30.5ft) at ISO 1600
– Tele: 0.4m (1.31ft) – 4.0m (13.1ft) at ISO 1600
Scene Modes16
– Portrait
– Beauty, Landscape, Hand-Held Starlight
– Night Scene, Night Scene with Portrait, Self-Portrait
– Indoor, Beach & Snow, Sports, Sunset, Fireworks
– Cuisine, Documents
– Pet (Dog), Pet(Cat)
Multi Recording Modes– Multi-Framing Videos
– Photo & Movie
– Photo with Movie clip
– Original Movie, Multi-File Movies & Magic Filter
Storage MediaSD, SDHC, SDXC card slot
Internal MemoryNO
Connectivity– USB 2.0 Hi-Speed
– HDMI mini connector
– DC input
– Combined USB & A/V output
Power Supply
BatteryLi-Ion 508mAh Rechargeable Battery
Shooting Capacity200 Shots
Other Features– TruePic III+ Engine
– 39 Menu Languages
– Internal Mic, AAC sound recording, Voice Playback
– Noise Reduction, Pixel Mapping
– Shading & Distortion Compensations
Colour AvailabilityBlack and Silver

Olympus SZ-30MR Specifications & Price

Price & Availability

Olympus SZ-30MR camera will be available from April in both the Black and Silver colors, with a price tag of $399.99 (£299.99).
